Brand New ISUZU CHINA 700P NPR 5 Cubic Meter Sewage Suction Truck 7870*2490*3550mm

Chassis Model:

QL1100A8KAY

Vehicle Parameters

Overall Dimension(L x W x H)

7870×2490×3550mm (subject to final design)

Curb Weight:

4900Kg

Loading Weight:

5100Kg

GVW:

10000Kg

Wheelbase:

3815mm

Drive Type:

4x2

Engine

Engine Model:

4HK1-TC51

Engine Power:

139(kw)

Displacement:

5193(ml)

Horsepower:

190HP

Transmission

Transmission:

MLD-6Q

Forword Gear:

6 Speed Gear

Reverse Gear:

1 Speed Gear

Seats

Front Seat:

3

Chassis

Front Track:

1680mm

Rear Track:

1650mm

Axle Loads:

Double Axles

Tires:

7(including spare tire)

Tire Model:

8.25R20

Configuration:

1

Power Steering

2

AC

3

Retro-reflective Marking

4

ABS

5

Free Maintenance Battery

6

Radial Tire

7

Air brake

Pressure/Vacuum tank

Material

St52

Capacity

3000L

Wall thickness

6mm

Head thickness

6mm

Design pressure

full vacuum

Working pressure

-0.98bar

Stiffening ring

Cold bend U-sectional external stiffening rings

Tipping cylinder

Front tipping cylinder for tank unloading at 45 degree

Safety support

safety valve for easy working under a tipped tank

Liquid level

mounted at the rear of tank body. Plugs at the top and bottom of indicator for removing sludge

Over pressure device

over pressure valve at the top of tank

Vent Valve

mounted to control the vacuum inside the tank

Discharge Gutter

At the rear of the tank in order to keep the rear of the vehicle clean

Rear cover

Operation

hydraulic operation

Safety

Hydraulic valve automatic check

Hinges

Heavy duty, adjustable hinges

Locking mechanism

Hydraulic operated clamp

Seal

Positive seal with rubber seal in neoprene

Inlet valve

check valve ND100mm

Outlet valve

check valve ND100mm

Vacuum pump

Type

water-cooled liquid ring vacuum pumps

Model

2BE1-153

Air flow

800 m³/hr

Max Vacuum

98%

Power requirement

20 kW

Speed

Max 1500 rpm

Drive line

engaged and disengaged in cab

Pump protection

venting ball valve inside tank body

filter

automatic vacuum sniffer valve

Cooling water tank

Capacity

1.000 L

Materia

St52

Wall thickness

4 mm

Type

Cylindrical tank, mounted just behind the cabin

Manhole

1 Off manhole, diam. 450mm
